Traka’s Modular Lockers are our most flexible locker framework and create a locker system that precisely fits the needs of any organization.
Available with 10 compartment sizes, and with a range of charging, RFID equipment identification and access control options these systems provide flexibility for storing and managing a variety of equipment, such as radios, scanners, medical equipment, or firearms together.
Traka's intelligent modular lockers provide an ideal solution to secure, manage and audit your organization’s valuable equipment - 24/7.
General features
Standalone features
Networked features
Optional features
Material data
Cabinet material: Zintec steel
Color options: Standard frames are RAL7021 (black grey) and doors RAL9003 (signal white). Other RAL colors are available upon request
Door material options: Perforated metal, solid metal or clear polycarbonate viewing window
Electrical data
Power supply: Input: 100-240V AC; Output: 15V DC
Battery backup: DC12V 7Ah
Power supply rating (without charging): 35W (max) with or without RFID
Power supply rating (with charging): As above plus electrical load required after consulting with Traka for more details
Environmental data
Operating temp: Ambient, for indoor use only (-5°C to +40°C / +23°F to +104°F at 95% non-condensing relative humidity)
Installation data
Mounting: Not suitable for freestanding applications. Must be securely fixed to a flat load bearing wall.
Network & connectivity data
Communications: Ethernet (AES-256 encryption)
Reader interface options: Clock/data, Wiegand, Serial (RS232/ TTL) PIN only, OSDP Readers (RS485) with or without Encryption
Alarm interface: x3 2A/30V DC max. rated relay contacts for connecting to alarms, access control systems, CCTV, etc.
Conformity & standards data
Certifications: UKCA (UK); CE (EU)
Quality: ISO9001
Standards: ISO14001
Information Security: ISO27001
Note: For a full list of technical specifications including weights and dimensions please refer to the product specification sheet in the Downloads section.
